GAS DETECTION

Portable Gas Detection

Send Enquiry

Multi Gas

Single or Two Gas

Calibration Gas, Kits & Accessories

Software Solutions

Regulators

K-600M 6 in 1 Multi Gas Detector with in built Pump

It adopts integrated built-in pump suction gas detection method, which can detect 6 kinds of gas at the same time. Imported miniature vacuum suction pump is adopted, with stable flow, long life and low noise. Marine Gas detector. The flow of the sampling pump is adjustable in 6 gears, which is suitable for different detection environments. The flow range is 300-800ml / min. Automatic alarm and prompt in case of sampling pump failure. Real time detection of temperature and humidity in the environment. Support the mode switching between real-time data display and real-time curve display of gas concentration. Support gas unit switching function. Support mixed gas calibration mode, convenient and fast. It supports external TF memory card storage mode and can read out the stored data through USB cable. It supports external TF memory card storage mode and can read out the stored data through USB cable. 10,0000 items External storage. CSV file format, data view at a glance. Various data storage methods, including alarm storage, fixed storage and manual storage. Support the expansion of pm2.5/pm10 detection module to obtain real-time particle concentration information. The measurement range is 0-1000 μ g / M 3 . Support external Bluetooth printer, real-time printing of detection data.. Support GPS positioning function. Large capacity (4000mAh) rechargeable lithium battery, longer service life . Explosion proof:Ex ib llC T3 Gb. Protection category: IP65.

Regulators

Gas Control Panel : BH-50 Gas Control Panel-four Channel / S-8000 Gas Controller / BH-KZ102 Combustible Gas Control Panel

This product is a single-channel / dual-channel / four-way (4-20) mA / RS485 transmitter signal input intelligent control system developed by the company. The product has high stability. High accuracy and high intelligence, the external control port is rich, the user can freely choose the type of the connected transmitter and the access port, and can perform on-site detection and alarm by simple setting. The system has integrated sound and light alarms and provides a relay normally open control terminal.

The system is widely used in applications where toxic and harmful gases need to be detected. When the index of a certain gas to be tested in the field exceeds or falls below the set standard, the system will perform a series of alarm actions, such as alarm, exhaust, tripping, etc.

Detection principle: Collect standard 4~20mA signal input or RS485 communication input (optional), analyze and display the current gas concentration of each channel, and operate related alarm signals, and transmit the information to the computer through RS485 bus.
Applicable objects: The system supports input signals of various standard detectors, such as gas detectors: carbon monoxide, hydrogen sulfide, sulfur dioxide, hydrogen, ammonia, oxygen, chlorine and combustible gases.
